P5mm Outdoor LED Display for Downtown Advertising and Public Spaces

Original price was: $14,999.00.Current price is: $10,599.00.

  • Display Size: 12.6′ × 6.3′
  • 5,200 NITS Brightness – Outdoor IP65 Rated
  • Includes Mirackle Mi1000 Video Processor
  • Rigging Bars, Cables & Spare Parts Included
  • Minimum Viewing Distance: 25 ft

P5mm Outdoor LED Display for Downtown Advertising and Public Spaces

Original price was: $14,999.00.Current price is: $10,599.00.

  • Display Size: 12.6′ × 6.3′
  • 5,200 NITS Brightness – Outdoor IP65 Rated
  • Includes Mirackle Mi1000 Video Processor
  • Rigging Bars, Cables & Spare Parts Included
  • Minimum Viewing Distance: 25 ft

U.S -Based Team

End-to-end Service

5-Year warranty

2-Day Shipping

Plug-n-play LED Panels

U.S -Based Team

End-to-end Service

5-Year
warranty

Plug-n-play LED Panels

Let's get in touch for your LED screen

Let's get in touch for your LED screen

P5mm Outdoor LED Display for Downtown Advertising and Public Spaces

In busy outdoor environments, visibility is not optional — it is the whole point. Our P5mm Outdoor LED Display is developed for downtown advertising, public spaces, commercial corridors, and high-traffic urban locations where content needs to stay bold, readable, and visually competitive throughout the day. When the audience is moving, driving, walking, or passing through, the screen has to communicate fast and hold attention immediately.

Built for Distance, Movement, and Outdoor Visibility

A screen in a downtown setting is rarely viewed from just a few feet away. It has to perform for pedestrians across the street, drivers approaching from a distance, and foot traffic moving through open public areas. That is where the 5mm pixel pitch becomes the right match, offering a practical balance between scale and readability for broad outdoor viewing.

Processing Power Is Already Working in the Background

MRV208-01 NovaStar 7680 Hz

The MRV208-1 NovaStar receiving card is part of what makes this system reliable in demanding outdoor applications. Paired with a 3840Hz refresh rate, it helps the wall maintain stable playback and smooth visual performance for animated ads, looping campaigns, digital signage, and outdoor promotional content that needs to run consistently throughout the day.

Advanced Processing with MRV208-1 NovaStar

MRV208-01 NovaStar 7680 Hz

Engineered for smooth motion and precise color, the MRV208-1 NovaStar transmitter card supports a 3840Hz refresh rate. It ensures flicker-free playback, deep color accuracy, and minimal latency, making it ideal for outdoor digital signage.

Free-Standing

A strong fit for outdoor advertising placements, public plazas, and commercial areas where the display needs to stand independently without relying on an existing wall structure. This method works especially well when the goal is to create a prominent visual landmark in open space.

Rigging

Useful for outdoor event setups, suspended signage concepts, or projects that require elevated placement for broader visibility. Rigging can also help create a more flexible installation when the display needs to work around surrounding structures or circulation patterns

Package Includes

(1)  Video Processor Mirackle Mi 1000 with HDMI, DVI and VGA Inputs

(4) Haggins bars for rigging

(8) Mirackle P5mm LED Video Panels

(4) Locking power to Edison link cables

(1) Cat6 25ft cable

(8) Data Cat6 cable

(8) Locking power link cables

Spare Parts

Package Includes

(8) Mirackle P1.5mm LED Video Panels

(8) Locking power link cables

(1)  Video Processor Mirackle Mi 1000 with HDMI, DVI and VGA Inputs

(4) Haggins bars for riggin.

(4) Locking power to Edison link cables

(8) Data Cat6 cable

(1) Cat6 25ft cable

Spare parts

View all categories and sizes of our LED displays

View all categories and
sizes of our LED displays

Technical Specifications

Key Features

  • Turn-key solution
  • Easy installation
  • Technical support available
  • 5-Year warranty included for all parts
  • USA-based
  • In stock

Power Supply

  • Operation Power: 100~240V 50-60Hz
  • Max. Power Consumption: 425W/per panel
  • Ave. Power Consumption: 240W/per panel
  • Connections Power/Data: Locking power In/Out; Data EtherCon In/Out

Control System

  • Control Mode: NovaStar Synchronous System with Control via DVI
  • Frame Update Frequency: 50-60Hz
  • Scan Mode: 1/8
    Refresh Rate: 3840Hz
  • Support Input: Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
  • Brightness Correction: Pixel, Module, Cabinet

Specs

  • Pixel Pitch: 5mm
  • LED Configuration: 3-in-1 SMD1820/1921 LED
  • Pixel Density: 192 x 192 per panel
  • Size: 37.8” x 37.8” x 3.5” / 960 x 960 x 88mm
  • Module Quantity: 18 per panel 320 x 160mm
  • Weight: 62lbs. / 30.9Kg

Optical Ratings

  • Brightness: 5200 NITS
  • Viewing Angle: Horizontal 140°/Vertical 140°
  • Distance: 25ft
  • Brightness Adjustment: 0~100% 100 Levels

Environmental

  • Operating Life: 100,000 Hours
  • Protection Level: IP65 (Front and Back)

Control System

  • (8) NovaStar P5mm  LED video panels
  • (1) Video Processor Mirackle Mi 1000 with HDMI, DVI and VGA Inputs
  • (4) Hanging bars for rigging
  • (1) Cat6 25ft cable
  • (8) Data Cat6 link cables
  • (8) Locking Power Link Cables
  • (4) Locking Power to Edison Cables
  • Spare parts included
