LED Video Panel P5mm INDOOR

If you’re looking for a reliable indoor LED display., the P5mm panel (960x960mm) is a solid choice for mid-range viewing. It’s designed to work well in places like event venues, office lobbies, malls, or auditoriums. With strong brightness levels and a clean display, it delivers consistent visuals that stand out without being over-the-top.

OPTIMAL VIEWING FOR MEDIUM DISTANCES

With a 5mm pixel pitch, this panel performs best when viewed from around 25 feet (7.5 meters) or more. That makes it a great fit for medium-sized spaces: hotels, lobbies, or indoor setups; where you need sharp graphics or images without getting too close to see the pixels.

SENDING CARD

NOVASTAR MRV208-1

This module panel comes equipped with a NovaStar MRV208-1 receiving card, which handles signal processing efficiently. Its 3840Hz refresh rate helps articulate smooth playback, especially for content that includes motion or quick transitions. It’s ideal for dynamic signage.

FULL FRONT SERVICE DESIGN

Tool-Free Magnetic Access for Rapid Maintenance

Maintenance is pretty straightforward with this one. Thanks to its magnetic front-access design, you can reach internal components without pulling the whole unit off the wall. If you’re managing a permanent install, this can save a lot of time when something needs adjusting, replacing or cleaning.

FREESTANDING STRUCTURE READY

If you’re setting up something temporary, like a trade show booth or a pop-up event, this module works just as well in a freestanding frame. It’s a versatile option for venues that can’t support permanent fixtures.

TRUSS AND CEILING RIGGING

The P5mm is compatible with standard truss and rigging systems, making it a go-to for stages, exhibitions, or concerts. Despite its size, it’s light enough for overhead setups while staying durable enough to handle frequent use.

Package Includes

(1) Video Processor NovaStar VX6S.

(5) Haggins bars for riggin.

(15) Mirackle P5mm LED Video Panels

(2) Locking power to Edison link cables

(1) Cat6 25ft cable

(15) Data Cat6 cable

(15) Locking power link cables

(15) Mirackle P1.5mm LED Video Panels

Package Includes

(15) Mirackle P1.5mm LED Video Panels

(15) Locking power link cables

(1) Video Processor NovaStar VX6S.

(5) Haggins bars for riggin.

(2) Locking power to Edison link cables

(15) Data Cat6 cable

(1) Cat6 25ft cable

(15) Mirackle P1.5mm LED Video Panels

View all categories and sizes of our LED displays

View all categories and
sizes of our LED displays

Technical Specifications

Key Features

  • Full Front Service / Magnetic Modules
  • Turn-key solution
  • Easy installation
  • Ground support compatible (sold separately)
  • Technical support available
  • 5-Year warranty included for all parts
  • USA-based
  • In stock

Power Supply

  • Operation Power: 100~240V 50-60Hz
  • Max. Power Consumption: 425W/per panel
  • Ave. Power Consumption: 240W/per panel
  • Connections Power/Data: Locking power In/Out; Data EtherCon In/Out

Control System

  • Control Mode: NovaStar Synchronous System with Control via DVI
  • Frame Update Frequency: 50-60Hz
  • Scan Mode: 1/16
  • Refresh Rate: 7680Hz
  • Support Input: Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
  • Brightness Correction: Pixel, Module, Cabinet

Specs

  • Pixel Pitch: 5mm
  • LED Configuration:3-in-1 SMD2121 LED
  • Pixel Density: 192 x 192 per panel
  • Size: 37.8” x 37.8” x 3.5” / 960 x 960 x 88mm
  • Module Quantity:
    18 per panel 320 x 160mm
  • Weight: 62lbs. / 30.9Kg

Optical Ratings

  • Brightness: 1000 NITS
  • Viewing Angle: Horizontal 140°/Vertical 140°
  • Distance: 25ft (7.6m)
  • Brightness Adjustment: 0~100% 100 Levels

Environmental

  • Operating Life: 100,000 Hours
  • Protection Level: IP45 (Front and Back)
